JVC TH-D5 Series User Manual

INSTRUCTIONSLVT1704-011B[US,UW,UG,UX,UA]TH-D7Consists of XV-THD7, SP-THD7W, SP-THD7F, SP-THD7C and SP-THD7STH-D5Consists of XV-THD5, SP-THD5W, SP-THD5

7You can enjoy surround sound by placing the speakers as illustrated (Speaker layout A or B).Speaker layout ASelect “S.SPK R” as the speaker position

8Make sure the antenna conductors do not touch any other terminals, connecting cords or power cords.Connect the TV to the appropriate video out jacks

9Connection using the component video jacksDo not connect the TVs via both the COMPONENT jacks and HDMI MONITOR OUT terminal at the same time.For the

10Audio connectionConnecting a digital componentThe initial setting for the audio input setting is “OPT.” When using COAXIAL jack, change the setting

11How to use the number buttonsTo select 3: Press 3.To select 10: Press 10.To select 14: Press h 10, 1, then 4.To select 24: Press h 10, 2, then 4.To

12Turning the power on or offTo turn off the System by using the sleep timerTo check the remaining time, press the button once.Selecting the sourceTo

13Selecting the speaker position modeSelect the speaker position mode according to your speaker layout ( 7).1 Turn off the System. ( 12)23 Select the

14Using the surround modeSelect one of the available surround modes.• During 2-channel playback with “S.SPK R” speaker position mode:• During multi-ch

154 Select an appropriate audio input according to the audio connection. ( 9)You can select the following settings for each source (underlined items a

16Starting playbackBe sure to reduce the volume on the System to the minimum level before connecting an iPod. Adjust the volume after playback has sta

G-1IMPORTANT FOR LASER PRODUCTS1. CLASS 1 LASER PRODUCT2. CAUTION: Do not open the top cover or cabinet. There are no user serviceable parts inside th

17Playing back a disc1 Select “DVD” as the source. ( 12)23 Place a disc on the tray.4 Start playback.• JPEG: Slide-show starts.• MP3/WMA/WAV: The file

18DO NOT connect or disconnect the device when the System is turned on.You cannot connect a computer to the USB MEMORY terminal of the System.DO NOT c

19For DVD Video/DVD Audio12 Select the desired item, then confirm the selection.For some discs, you can also select items by using the number buttons.

20 Programing the playing order—program play12 Select the desired chapters/tracks.• For DVD Video, DVD Audio, MP3 and WMA: Enter a title/group number,

21Changing the language/sound/scene angleFor DVD Audio, the functions take effect for the moving picture part only.*1For DVD VR and SVCD discs, the su

22Adjusting the picture quality (VFP)You can adjust the picture mode.12 Select the desired preset, then finish the setting.To adjust the picture tone1

23Using the on-screen barYou can use various functions from the on-screen bar.Basic operation procedure12 Select the desired item (see the right colum

24Using the file control display The file control display appears in the following cases.– Audio files: Always appears.– Movie and picture files: When

25You can change the settings of the System according to your preferences and playing environment. 12 Select the menu.3 Select the item, then confirm.

26Picture menu (PICTURE)MONITOR TYPE Select 16:9 wide-screen playback to fit on your monitor.PICTURE SOURCESelect the source type of the disc/file con

G-2Caution: Proper VentilationTo avoid risk of electric shock and fire and to protect from damage, place the apparatus on a level surface. The minimal

27SPK.SETTING menu is available only when the speaker position mode is set to “S.SPK R” ( 13).Speaker setting menu (SPK.SETTING)LEVEL Adjust the outpu

28Some countries space AM stations 9 kHz apart, and some countries use 10 kHz spacing.You can only change the AM tuner interval spacing while selectin

291 Connect the microphone(s) to the MIC 1 or/and MIC 2 jack on the center unit.2 Select “DVD” as the source.3 Activate the Karaoke function.4 Start p

30The audio channel can be selectable with most of the Karaoke discs.Each time you press AUDIO, the audio channel changes as follows:• Example for a V

31Before operating external components from the remote control, set the manufacturer’s code.1 Set the remote control mode (see above).2 Press and hold

32TVDBS tuner or CATV converterVCR* Initial settingManufacturers’ codes are subject to change without notice.Manufacturer’s code listJVC 01* Samsung 1

33You can change the setting so that the on-screen guide icons do not appear on the TV. ( 27)Power does not come on.ZThe power plug is not inserted se

34Video and audio are distorted.ZThe disc is scratched or dirty.ZAudio/video files have not been properly copied on to the USB mass storage class devi

35Center unit (XV-THD7/XV-THD5)Output powerFront:140 W per channel, RMS at 4 Ω at 1 kHz, with 10 % total harmonic distortion.Center:130 W, RMS at 4 Ω

36Satellite speakers (For TH-D7)Front speakers (SP-THD7F)Type:2-Way 3-Speaker Bass-Reflex Type (Magnetically Shielded Type)Speaker: 8 cm cone × 23 cm

1How to read this manual• Illustrations and button names of the TH-D7 are mainly used for explanation.• The following icons and illustrations are used

DVD DIGITAL CINEMA SYSTEM0607RYMMDWJMMEN© 2007 Victor Company of Japan, LimitedTH-D7/TH-D5Mains (AC) Line InstructionCAUTION for mains (AC) lineBEFORE

2Notes on installing the System• Select a location which is level, dry and neither too hot nor too cold between 5°C and 35°C.• Do not install the Syst

3This System accommodates the PAL and NTSC system.It is possible to play back finalized +R/+RW (DVD Video format only) discs. “DVD” lights on the disp

4USB mass storage class deviceA USB flash memory device, hard disk drive, multimedia card reader, digital camera, etc. can be used with this System th

5If anything is missing, contact your dealer immediately.• Remote control (x 1)• Batteries (x 2)• FM antenna (x 1)• AM loop antenna (x 1)• Composite v

6If you connect speakers other than those supplied for the System, use speakers of the same speaker impedance (SPEAKER IMPEDANCE) indicated on the rea
